MAIN FEATURES
- Working height: up to 5.4m
- Working load: 300kg
- Small body: easy to store, transport, access standard doors, elevator doors
- Optional extension platform: increases the working scope of the operator
- The battery is used as a power source, with low noise and no pollution, suitable for various operating environment points
Technical Specifications
| Model No. | --- | SYJ0.3-3 | SYJ0.3-3.9 | |
| Capacity | kg | 300 | 300 | |
| Max Platform Height | mm | 3000 | 3900 | |
| Min Platform Height | mm | 630 | 700 | |
| Platform Size | mm | 1170x600 | ||
| Elevating Time | sec | 33 | 33 | |
| Lifting Motor | V/kW | 12/0.8 | 12/0.8 | |
| Charger | V/A | 12/15 | 12/15 | |
| Overall Length | mm | 1300 | 1300 | |
| Overall Width | mm | 740 | 740 | |
| Overall Height | mm | 1650 | 1750 | |
| Net Weight | kg | 360 | 420 | |
