MAIN FEATURES
- Handle or foot lever option to discharge the load
- Extremely small turning radius grants it to be operated in narrow spaces
- C frame structure ensures more stable and secure lift
- Fixed pallet fork and movable pallet fork as per requirement
Technical Specifications
| Model | --- | GMS1016 | GMS1516 | GMS2016 |
| Capacity | kg | 1000 | 1500 | 2000 |
| Max. Lifting Height | mm | 1600 | ||
| Lowered Fork Height | mm | 85 | ||
| Fork Length | mm | 1000 | ||
| Fork Span | mm | 330 - 550/740 (optional) | ||
| Front Wheel Size | mm | 80 x 58 | ||
| Back Wheel Size | mm | 180 x 50 | ||
| Overall Dimensions | mm | 1600x760x2030 | ||
| Net Weight | kg | 224 | 240 | 270 |
