MAIN FEATURES
- High-quality maintenance-free batteries
- Forged/Fabricated fork as per requirement
- Quick charging time
- Excellent stability
Technical Specifications
| Model | --- | SEM1020 | SEM1025 | SEM1030 | SEM1035 | SEM1520 | SEM1525 | SEM1530 | SEM1535 | SEM2020 |
| Rated Capacity | kg | 1000 | 1000 | 1000 | 1000 | 1500 | 1500 | 1500 | 1500 | 2000 |
| Max. Fork Height | mm | 2000 | 2500 | 3000 | 3500 | 2000 | 2500 | 3000 | 3500 | 2000 |
| Max. Machine Height | mm | 2560 | 3060 | 3060 | 4060 | 2560 | 3060 | 3560 | 4060 | 2560 |
| Fork Length | mm | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
| Fork Width | mm | 330 - 850 | 330 - 850 | 330 - 850 | 330 - 850 | 330 - 850 | 330 - 850 | 330 - 850 | 330 - 850 | 330 - 850 |
| Min. Turning Radius | mm | 1350 | 1350 | 1450 | 1450 | 1350 | 1350 | 1450 | 1450 | 1350 |
| Lifting Motor | V/kW | 12/1.6 | ||||||||
| Battery | V/Ah | 12/120 | ||||||||
| Charger | V/A | 12/15 | ||||||||
| Overall Length | mm | 1600 | ||||||||
| Overall Width | mm | 865 | 865 | 930 | 930 | 865 | 865 | 930 | 930 | 865 |
| Overall Height | mm | 1580 | 1830 | 2080 | 2330 | 1580 | 1830 | 2080 | 2330 | 1580 |
| Net Weight | kg | 425 | 450 | 470 | 500 | 450 | 475 | 495 | 520 | 470 |
